Sony PXW-FX9

Properties:

The PXW-FX9 is an addition to the popular FS-series and offers numerous improvements compared to the PXW-FS7 II. It features a 6K full-frame Exmor R CMOS sensor (35.7 x 18.8 mm), Dual Base ISO between ISO800 and ISO4000, reproduces natural colours with soft skin tones thanks to cinematic colour technology S-Cinetone™, derived from the experience of the VENICE digital cine camera, and has a high dynamic range of 15+ f-stops for vibrant shots. The autofocus technology Fast Hybrid AF combines the advantages of phase detection AF and contrast AF for fast and reliable focusing. The camera's LCD monitor has also been revised compared to the PXW-FS7 II and now offers a resolution of 1280 x 720 pixels instead of 960 x 540 pixels. The PXW-FX9 also features internal Wi-Fi, eliminating the need for an external USB Wi-Fi dongle. The FX9 can record 4K DCI at up to 60 frames per second and Full HD at up to 180 frames per second (after future firmware updates). The XAVC Intra, XAVC Long and MPEG HD422 codecs are available for this purpose. For example, the PXW-FX9 can record UHD (3840 x 2160 pixels) as XAVC Intra in 4:2:2 10-bit at a maximum bitrate of 600 Mbps on up to two XQD cards. An SD card slot for proxy files is also available. New is also a 12G-SDI output, which can output video resolutions up to UHD (2160p60). A built-in variable electronic ND filter rounds off the diversity of the PXW-FX9 and makes the use of external ND filters unnecessary. The camera is powered by a BP-U type li-ion battery, such as the Sony BP-U70, or by a 19.5 V DC power input. The PXW-FX9 is covered by 2 years of PrimeSupport Pro as a standard included service package. This includes a standard repair with the highest effort and short processing times. The duration of the service package can be extended to 3 years if it is registered on the manufacturer's website within 60 days after purchase.

• Full-frame oversampling technology for stunning 4K and HD recordings
• High light sensitivity and high dynamic range with 15+ f-stops
• Cinematic colour technology S-Cinetone™ for natural and soft skin tones
• Fast Hybrid AF with large 561-point image coverage for fast and reliable focusing
• Variable electronic ND filter
• Internal recording in 4K 4:2:2 10-bit
• Recording in RAW (after future firmware update)
• Revised camera grip for more comfortable handling
• Dual Base ISO for day and night motifs

Technical Specifications:

• Sensor: 6K full-frame Exmor R CMOS (35.7 x 18.8 mm), backlit
• Native Resolution: 6008 x 3168 pixels
• Total Pixels: 19 MP (6K full-frame), 8.8MP (4K Super 35)
• Dynamic Range: 15+ f-stops
• Monitor: 3.5" HD-LCD (1280 x 720 pixels) with 2.76 million dots
• Image Stabilization: Built-in gyro with camera shake recording for eliminating in post-production
• Dual Base ISO: Switchable between ISO800 (Low Base) and ISO4000 (High Base), S-Log3 and Cine El mode only
• Autofocus: Fast Hybrid AF (Phase Detection AF and Contrast AF), Face Detection AF (3 modes), One Push AF
• Autofocus Settings: Transition speed (1 - 7), subject shift sensitivity (1 - 7)
• Neutral Density Filters: Clear, ND2, ND4, ND6 - ND128, variable
• Codecs: XAVC Intra, XAVC Long, MPEG HD422
• Colour Sampling: 4:2:2 10-bit (XAVC Intra, XAVC Long), 4:2:2 8-bit (MPEG HD422), 4:2:0 8-bit (XAVC Long)
• Bitrate: 25 - 600 Mbps (depending on codec, colour sampling and video resolution)
• Colour Gamut: S-Log3 (gamma), S-Gamut3 / S-Gamut3.Cine (colour space)
• Supported Video Resolutions (Full-Frame):
  4K DCI - 4096 x 2160p / 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 (after future firmware update)
  QFHD / UHD - 3840 x 2160p / 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 (50 - 60p after future firmware update)
  2K DCI - 2048 x 1080p / 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 / 100 / 120 / 150 / 180 (possibly after future firmware update) Full HD - 1920 x 1080p / 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 / 100 / 120 / 150 / 180 (150, 180p after future firmware update)
  Full HD - 1920 x 1080i / 50 / 59.94 / 60
• Supported Video Resolutions (Super 35):
  4K DCI - 4096 x 2160p / 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 (after future firmware update)
  QFHD / UHD - 3840 x 2160p / 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 / 100 / 120 (100, 120p after future firmware update)
  2K DCI - 2048 x 1080p / 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 / 100 / 120 (possibly after future firmware update)
  Full HD - 1920 x 1080p / 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 / 100 / 120
  Full HD - 1920 x 1080i / 50 / 59.94 / 60
• Compatible Storage Media: 2x XQD card, 1x SD card
• Connectivity: Internal Wi-Fi, NFC, GPS
• Lens Mount: Sony E-mount

Data Links:

Input

• 2x Audio via 3-pin XLR (4-channel, with switchable +48 V phantom power)
• 2x Storage media via XQD card
• 1x Storage media via SD card
• 1x Power supply DC (19.5 V)

Output

• 1x 12G-SDI via BNC
• 1x 3G-SDI via BNC
• 1x HDMI via HDMI-A
• 1x Headphones via 3.5 mm mini jack
• 1x Power supply DC via 4-pin Hirose
• 1x Power supply DC via 2-pin D-Tap

Others

• 1x Timecode via BNC
• 1x Genlock IN / Sync OUT via BNC
• 1x Remote via 2.5 mm jack
• 1x USB via Micro-USB
• 1x Ethernet via RJ-45

General Product Information:

• Dimensions (W x H x D): 146 x 142.5 x 229 mm (5.74 x 5.61 x 9 in)
• Weight (body only): approx. 2 kg (4.4 lb)
• Operating Temperature: 0° to +40° C (+32° to +104° F)
• Storage Temperature: -20° to +60° C (-4° to +140° F)
• Operating Voltage: 19.5 V DC
• Power Consumption: approx. 35.2 W
• Battery Runtime: approx. 54 min (with BP-U35), approx. 108 min (with BP-U70)

Scope of Delivery:

• 1x Camera body with top handle, microphone holder and LCD monitor
• 1x Body cap
• 1x Viewfinder
• 1x Grip remote control
• 1x AC adapter
• 1x Battery BP-U35
• 1x Battery charger BC-U1A
• 2x Power cable
• 1x USB cable
• 2x Instruction manual
• 1x CD-ROM (Manuals for Solid-State Memory Camcorder)
